FAVO™ 5 Flow Reactor

The FAVO™ Flow Reactors, high-performance process equipment that unlocks electrochemistry beyond the state of the art.

FAVO™ 5 Flow Reactor

New in the lineup of Creaflow is the FAVO™ 5 Flow Reactor. Built on the game-changing COSTA™ Technology, the FAVO™ 5 Flow Reactor allows on-demand control over mass transfer and results in unrivaled productivity rates (up to 4-fold) as compared to the steady-state flow operation. The dual-pulse technology (i.e., flow and voltage pulsation) is unprecedented and unlocks breakthrough applications in the field of organic electrochemistry. The reactor is equipped with an integrated heat exchanger for maximum process control and the interchangeable Electrode Inlay (E-Inlay) technology reveals a modular, yet robust, reactor platform with ultimate adaptability, while securing unmatched temperature and pressure rating (i.e., -20 to 150 °C and up to 25 barg).

(Download Flyer Below)

User Applications:

Laboratory R&D phase (mg to multi-gram scale)
Organic electrochemistry
Demanding multi-phase processes (e.g. slurry-based, gas-evolving processes)
Single-pass operations for longer residence time reactions (without affecting mass transfer)
Compatible with various electrode materials
High-pressure application (up to 25 bar)

Available Reactor Assemblies:

Assembly FAVO™ 5 FAVO 5 PRO
Art. No. S10195 S10196
Version v1.2 v1.2
Internal Volume 5 mL 5 mL
Temp. Range -20 to 100 °C -20 to 150 °C
Pressure Rating 10 barg (16 barg at RT) 25 barg
Heat Exchanger Heat transfer fluid system Heat transfer fluid system
Wetted Parts Impervious graphite E-Inlay set (electrodes), PEEK (in/outlet ports), PTFE, FFKM, FEP Platinum coated E-inlay set (electrodes), Hastelloy C276 (in/outlet ports), PTFE, FFKM, FEP
E-Inlay Pattern Two-comb, cubic 2x2 Two-comb, cubic 2x2
Max. Particle Size 200 µm 200 µm
E-Inlay/Ports Exchangeable Exchangeable
Process Connections UNF ¼-28 Female 1/8” NPT Female (adaptors available)
Large Bore Tubing - Compatible
Temp. Probe Sockets - In/outlet ports
Throughput 0.1 - 35 mL/min (mg/h to g/d) 0.1 - 35 mL/min (mg/h to g/d)
Outer Dimensions 25 x 9 x 7 cm (L x W x H) 25 x 9 x 7 cm (L x W x H)
Pulsator Specifications:
Freq. Range 0 - 3 Hz 0 - 3 Hz
Volume Displacement 0.44mL @ 100% ampl. stroke 0.44mL @ 100% ampl. stroke
Wetted Parts PTFE, carbon filled PTFE Hastelloy C276, PTFE
Connection Ports UNF ¼-28 Female 1/8" NPT Female (adaptors available)

Click here for accessories
